CY-290 High speed flat bottom paper bag making machine
- Product description
High speed flat bottom paper bag making machine
CY-290 High speed flat bottom paper bag making machine is designed to manufacture flat bottom paper bags from paper roll in blank or printed. Side gluing, tube forming, cutting, bottom creasing, bottom gluing, bottom forming and final product out feed can be completed within one time by this paper bag machine.
High speed flat bottom paper bag making machine is ideal equipment for making paper bag for foodstuff bag, shopping bag and so on. Controlled by PLC system, equipped with in-touch screen and servo motor for bag length control, High speed flat bottom paper bag making machine can produce different size paper bag.
Model |
CY-290/460 paper bag making machine |
Paper Roll width Tube length |
320-900mm (12.60*-36.61") /600-1300mm (23.62"-5118") 260-533mm (10 24"-20 99") /260.4-533 4mm (10 25*-21") |
Bag Width Bottom Size |
120-290mm (4.72*-1142" ) /220-460mm (8 66 18 11 ) 60- 160mm (2 36"-6 30") / 60 160mm (2 36*"-6 30" ) |
Paper Thickness Max Paper Roll Diameter |
60-150gsm /60-150gsm φ1300mm (51" ) /φ 1300mm (51" ) |
Material Core Diameter Max.Production Speed |
φ76mm(2.99") / φ76mm(2.99'") 200p cs/min /180pcs/min |
Total Power Machine Weight |
15kw/ 15kw 8500kg/10000kg |
Machine Size (LxWxH) |
8600mmx2500mmx1800mm /800m3000mx1800mm |
